Farsoon introduces large-format metal PBF system

Key Takeaways

• Farsoon Technologies introduces the FS1311M-U, a large-format metal Powder Bed Fusion (PBF) system for industrial additive manufacturing
• The system has a build volume of 1310 × 1310 × 1650 mm, suitable for large metal parts and batch production
• The FS1311M-U features a 16-laser configuration, optional beam shaping technology, and build rates of up to 1440 cm³/h in Ti-6Al-4V at 150 µm layer thickness
• The system prioritizes quality and process stability with features like optical systems, multi-laser overlap, and recoating monitoring
• The FS1311M-U includes production workflow and system control features like MES connectivity, closed-loop powder management, and real-time process monitoring

Introduction to the FS1311M-U

Farsoon Technologies has announced the launch of the FS1311M-U, a large-format metal Powder Bed Fusion (PBF) system designed to address production throughput, batch consistency, and process control in industrial additive manufacturing. This system is targeted at manufacturing sectors such as aerospace, automotive, and energy, where the production of large metal parts and batch builds is crucial.

Built for Large-Scale Production

The FS1311M-U boasts a build volume of 1310 × 1310 × 1650 mm, making it an ideal solution for manufacturing large integrated parts and batch production. Despite its large build volume, the system has a compact footprint, which is beneficial for manufacturing environments where floor space is limited. This feature allows companies to maximize their production capacity without requiring excessive floor space.

Laser Configuration and Build Rate

The FS1311M-U features a 16-laser configuration and offers optional beam shaping technology. This setup supports wider scan spacing, thicker layers, and higher scanning speeds, resulting in build rates of up to 1440 cm³/h in Ti-6Al-4V at 150 µm layer thickness. The following comparison table highlights the key features of the FS1311M-U's laser configuration:

Quality and Process Stability

The FS1311M-U prioritizes quality and process stability with features like optical systems, multi-laser overlap, and recoating monitoring. The system's airflow design combines multi-layer gas flow with an air-wall structure to reduce turbulence and limit contamination across the build area. These features ensure repeatable builds and high-quality metal parts.

Production Workflow and System Control

The FS1311M-U includes production workflow and system control features like MES connectivity, a closed-loop powder management platform, and a three-station design for parallel operations. The system also uses Farsoon's control card and supporting hardware, along with permanent filtration for longer build jobs and real-time process monitoring. These features support production continuity, safety, and operational control.

Bottom Line

The Farsoon FS1311M-U is a large-format metal PBF system that addresses the needs of industrial additive manufacturing. With its large build volume, 16-laser configuration, and features prioritizing quality and process stability, this system is an ideal solution for manufacturing large metal parts and batch production. The FS1311M-U's production workflow and system control features ensure production continuity, safety, and operational control, making it a valuable addition to any manufacturing environment.
